60°, 90°, 345°, 350°, 355° electrical angle
6 mm shaft diameter
±0.5% linearity
1000 RPM operating speed
Long life up to 10 million movements
IP40 protection class
Rotary potentiometer with shaft; synchro size 20; movement life up to 10 million ; infinite and continuous rotation; 2 or 3 potentiometric outputs in one product
| Measuring Range | Shaft Diameter | Body Diameter | Output Type | Protection | Linearity | Datasheet |
|---|---|---|---|---|---|---|
| 60°, 90°, 345°, 350°, 355° |
6 mm
|
52.8 mm
|
Potentiometric (2 or 3 outputs)
|
IP40
|
±0.5% |  |
Spring-return (self-return)
60°, 110° or 120° electrical angle
120° or 150° limited mechanical angle
M6x1 threaded shaft (optional others)
30 mm body diameter
Potentiometric output
±%1 linearity
2 million cycyles lifetime
IP67 protection
Rotary potentiometer with spring return; Up to 2 million movement life; Self-return feature; potentiometric output, high protection class
| Measuring Range | Shaft Diameter | Body Diameter | Output Type | Protection | Linearity | Datasheet |
|---|---|---|---|---|---|---|
| Electrical Ang: 60°, 110°, 120° Mechanical Ang: 120°, 150° |
M6x1
|
30 mm
|
Potentiometric
|
IP67
|
±%1 | |
Spring-return (self-return)
Bidirectional Electrical Angle: ±60° (Total 120°)
Bidirectional Mechanical Angle: ±62,5° (Total 125°)
(There is a 5° dead zone in the center)
6 mm shaft (optional others)
36 mm body diameter
Potentiometric output
±%1 linearity
2 million cycyles lifetime
IP54 protection
Rotary potentiometer with spring return; Up to 2 million movement life; Self-return feature; Bidirectional potentiometric output
| Measuring Range | Shaft Diameter | Body Diameter | Output Type | Protection | Linearity | Datasheet |
|---|---|---|---|---|---|---|
| Electrical Ang: ±60° ( total 120°) Mechanical Ang:±62,5° (Total 125°) |
6 mm
|
36 mm
|
Potentiometric
|
IP54
|
±%1 | |
II 1G Ex ia IIC T4/T6 Ga
II 1D Ex ia IIIC T120°C / T85°C Da
ATEX ve IECEx
Ex Zones 0, 1, 2 (gas); 20, 21, 22 (dust)
Different models available from 100 mBar to 600 Bar
nalog output (4-20mA / 0-10V, etc.) or CANopen output
±%0,3 F.S accuracy
IP65 or IP67 protection
Compact design
ATEX certified for use in explosive atmospheres; high accuracy; protected against EMC and reverse polarity; small and compact design
| Measuring Range | Output | Protection | Accuracy | Body Diameter | Datasheet |
|---|---|---|---|---|---|
| Different models from 0…100mbar to 0…600bar Different vacuum models from 0…-100mbar to 0…-1bar | 4-20 mA, 0-10 VDC, Ratiometric or CANopen | IP65 or IP67 | ±%0,3 F.S | 22mm | |
Thin-film steel diaphragm structure
26 mm diameter stainless steel housing
Different options up to 2000 Bar
Analog 4-20mA / 0-10V etc. outputs
±%0,5 F.S accuracy
Compact design
Fully welded Thin-film steel diaphragm structure that does not require O-rings; High sensitivity; EMC and reverse polarition protection; Small and compact design
| Pressure Range | Output | Protection | Accuracy | Body Diameter | Datasheet |
|---|---|---|---|---|---|
| Different options up to 2000 Bar | 4-20 mA, 0-10 VDC, 0-20 mA, 1-6 VDC, 0-5 VDC, Ratiometric | IP65 or IP67 | ±%0,5 F.S | 26mm | |
Resistant to most oils, fuels, hydraulics, dust and solvents
Mechanical switch for 10mA – 5A at 9-32VDC
Vibration (5G) resistant
Designed to allow both vertical and angular movement
Standard NO, optional NC switch output
IP67 protection class
Oil, fuel, hydraulic and dust resistant; resistant to vibrations; commercial vehicles, industrial equipment, conveyor systems, etc. Status detection and output for many different situations that may occur in systems
| Voltage and Current Range | temperature Range | Body Diameter | Output | Protection | Datasheet |
|---|---|---|---|---|---|
| 12-24V / 10mA-5A | -40°C … +150°C | 26mm | NC or NO | IP67 | |
Resistant to most oils, fuels, hydraulics, dust and solvents
Mechanical switch for 10mA – 5A at 9-32VDC
Vibration (5G) resistant
Designed to allow both vertical and angular movement
Standard NC, optional NO switch output
Industry standard AMP superseal connector
IP69K protection class
Oil, fuel, hydraulic and dust resistant; resistant to vibrations; commercial vehicles, industrial equipment, conveyor systems, etc. Status detection and output for many different situations that may occur in systems
| Voltage and Current Range | temperature Range | Body Diameter | Output | Protection | Datasheet |
|---|---|---|---|---|---|
| 12-24V / 10mA-5A | -40°C … +150°C | 27mm | NC or NO | IP69K | |
Suitable for mineral oils
Alarm delay time between 0-40 seconds can be selected at the ordering stage
40 Bar pressure resistance
Sink (NPN) or source (PNP) output type
High accuracy and stability
IP67 protection class
Suitable for level measurement in mineral oils, sink (NPN) or source (PNP) output, selectable alarm delay time between 0-40 seconds
| Application | Max Pressure | Temperature Range | Output Type | Mechanical Connection | Protection | Datasheet |
|---|---|---|---|---|---|---|
| Mineral oils | 40 bar | -40°C … +125°C | Sink (NPN) or Source (PNP) | 1/4”NPTF, 3/8”NPTF, 1/2”NPTF, 1/2”BSPP, 1/2”BSPT, M14x1.5, M18x1.5 | IP67 | |
Non-contact distance measurement with laser (TOF)
940 nm invisible laser (VCSEL), Class 2
2000mm mesauring range
12mm small body diamater
Analog, CANopen, MODBUS and switch output options
IP67 protection class
Precise non-contact distance measurement and approximation detection with laser beam; small and compact structure; Analog, switch, CANopen or MODBUS interface options
| Measuring Range | Output | Field of View | Accuracy | Protection | Datasheet |
|---|---|---|---|---|---|
| 2000 mm | 4-20 mA, 0-20 mA, 0-10V, 0-5V, CANopen, RS-485, PNP Open Collector | 18° | ±%2 FS | IP67 | |
Pressure and temperature measurement with a single sensor
Completely welded thin-film steel diaphragm structure that does not require o-ring
Pressure measuring range options from 0…6 bar to 0…1000 bar (optional others)
-40 … +150°C temperature measurement (optional others)
4-20mA, 0-10V, 0.5-4.5V Ratiometric, PT100, PT1000 output options
G1/4, G1/2, NPT1/4, NPT1/2, M14x1 process connection options
High accuracy and stability
Measurement of both pressure and temperature via a single sensor; Fully welded Thin-film steel diaphragm structure that does not require O-rings; high sensitivity; EMC and reverse polarization protection; wide range of analog output and mechanical connection options
| Measuring Range | Output | Mechanical Connection | Protection | Datasheet |
|---|---|---|---|---|
| Temperature: -40ºC … +150ºC (opt. others) Pressure: 6… 1000 bar (opt. others) |
4-20mA, 0-10V, 0.5-4.5V Ratiometric, RTD | G1/4, G1/2, NPT1/4, NPT1/2, M14x1 vb. | IP65 or IP67 | |
Pressure and temperature measurement with a single sensor
Completely welded thin-film steel diaphragm structure that does not require o-ring
Pressure measuring range options from 0…10 bar to 0…2000 bar (optional others)
-40 … +150°C temperature measurement (optional others)
4-20mA, 0-10V, 0.5-4.5V Ratiometric, PT100, PT1000 output options
High accuracy and stability
Measurement of both pressure and temperature via a single sensor; Fully welded Thin-film steel diaphragm structure that does not require O-rings; high sensitivity; EMC and reverse polarization protection; wide range of analog output and mechanical connection options
| Measuring Range | Output | Mechanical Connection | Protection | Datasheet |
|---|---|---|---|---|
| Temperature: -40ºC … +150ºC (opt.others) Pressure: 10… 2000 bar (opt.others) |
4-20mA, 0-10V, 0.5-4.5V Ratiometric, RTD | G1/4 | IP65 or IP67 | |
Detection of ferrous metal objects by inductive principle
17x17mm, 25x25mm and 30x30mm models
Rectangular type
DC 2-wire or 3-wire
LED status indicator
IP67 protection
Non-contact measurement of ferrous metal objects by inductive principle; DC 2-wire or 3-wire; rectangular body; various body dimension options; long service life
| Body Dimensions (mm) | Sensing Distance | Setting Distance | Output Type | Protection | Datasheet |
|---|---|---|---|---|---|
| 17×17 25×25 30×30 |
17×17:0 … 8 mm 25×25:0 … 8 mm 30×30:0 … 15 mm |
17×17:0 … 5.6 mm 25×25:0 … 5.6 mm 30×30:0 … 11 mm |
2-wire 3-wire NPN 3-wire PNP |
IP67 | |
