Pressure Transmitters

Ceramic diaphragm
Stainless steel body
Options from 0 … 1 bar to 0 … 400 bar
±0.5% FS sensitivity
Different analog output options
IP65, IP67 or IP68 protection class
Economical and convenient solution
Datashee

Pressure transmitter with ceramic diaphragm; economical and durable solution; relative or absolute measurement option

Datasheet

Measuring Range	Output	Protection	Accuracy	Datasheet
0 … 1 to 0 … 400 bar	4-20 mA, 0-10 VDC, 0.5-4.5 VDC ratiometric, 0-5 VDC, 1-6 VDC	IP65, IP67, IP68	±%0.5 FS

Ceramic diaphragm
Stainless steel body
Options from 0 … 100 millibar to 0 … 40 bar
±0.3% FS sensitivity
Different analog output options
IP65, IP67 or IP68 protection class
Economical and convenient solution

Special series pressure transmitter for low pressures with ceramic diaphragm; economical and durable solution; relative or absolute measurement option

Datasheet

Measuring Range	Output	Protection	Accuracy	Datasheet
0 … 0.1 to 0 … 40 bar	4-20 mA, 0-10 VDC, 0.5-4.5 VDC ratiometric, 0-5 VDC, 1-6 VDC	IP65, IP67, IP68	±%0.3 FS

Marine certified
With ceramic diaphragm
Stainless steel or titanium body
Options from 0 … 0.1 bar to 0 … 250 bar
±0.3% FS sensitivity
4-20 mA analog output
IP65, IP67 or IP68 protection class
Economical and convenient solution

Pressure transmitter with ceramic diaphragm; marine certified; economic and durable; relative or absolute measurement option

Datasheet

Measuring Range	Output	Protection	Accuracy	Datasheet
0 … 0.1 to 0 … 250 bar	4-20 mA	IP65, IP67, IP68	±%0.3 FS

Thin film steel diaphragm
Stainless steel housing, high pressure resistant
Measurements from 0 … 2,5 bar to 0 … 600 bar
High sensitivity of ±0.3% and ±0.5% FS
Different analog output options
Wide temperature range up to 125°C
IP65, IP67 or IP68 protection class

Pressure transmitter with steel diaphragm; one-piece welded sealing body provides high durability and resistance to ambient conditions; very small compact design

Datasheet

Measuring Range	Output	Protection	Accuracy	Datasheet
0 … 2.5 to 0 … 600 bar	4-20 mA, 0-10 VDC, 0.5-4.5 VDC ratiometric, 0-5 VDC, 1-6 VDC	IP65, IP67, IP68	±%0.5 FS, ±%0.3 FS

Thin film steel diaphragm
Stainless steel body
Options from 0 … 2,5 bar to 0 … 600 bar
±0.5% FS sensitivity
Different analog output options
Optional switching output
IP 65, IP67 or IP68 protection class

Pressure transmitter with steel diaphragm; High durability and unaffected by environmental conditions thanks to its one-piece welded, leak-proof body; very small compact design

Datasheet

Measuring Range	Output	Protection	Accuracy	Datasheet
0 … 2.5 to 0 … 600 bar	4-20 mA, 0-10 VDC, 0.5-4.5 VDC ratiometric, 0-5 VDC, 1-6 VDC, optional switching output	IP65, IP67, IP68	±%0.5 FS

Piezoresistive working principle
Stainless steel housing (1.4305)
Optional 316L or titanium housing
Different models between 100 mBar and 600 Bar
Analog 4-20mA / 0-10V and CANopen output options
±0.5% F.S or ± 0.3% F.S accuracy
IP65 or IP67 protection class
Compact construction

Stainless steel body; high sensitivity; EMC and reverse polarization protected; small and compact design

Datasheet

Measuring Range	Output	Protection	Accuracy	Body Diameter	Datasheet
Different models from 0…100mbar to 0…600bar  Different vacuum models from 0…-100mbar to 0…-1bar	4-20 mA, 0-10 VDC, 0-20 mA, 1-6 VDC, 0-5 VDC, Ratiometric or CANopen	IP65 or IP67	±%0,5 F.S (ceramic), ±%0,3 F.S (silicon)	22mm

Piezoresistive working principle
Stainless steel housing (1.4305)
Optional 316L or titanium housing
Different models between 100 mBar and 600 Bar
Analog 4-20mA / 0-10V and so on different outputs
±0.3% F.S accuracy
IP65 or IP67 protection class
Compact construction

Stainless steel body; high sensitivity; EMC and reverse polarization protected; small and compact design

Datasheet

Measuring Range	Output	Protection	Accuracy	Body Diameter	Datasheet
Different models from 0…100mbar to 0…600bar Different vacuum models from 0…-100mbar to 0…-1bar	4-20 mA, 0-10 VDC, 0-20 mA, 1-6 VDC, 0-5 VDC, Ratiometric etc.	IP65 or IP67	±%0,3 F.S	26mm

Piezoresistive working principle
Stainless steel housing
10Bar and 16Bar models
4-20mA analog output
±0.5% F.S accuracy
IP65 protection class
Compact construction

Stainless steel body; high sensitivity; EMC and reverse polarization protected; small and compact design

Datasheet

Measuring Range	Output	Protection	Accuracy	Body Diameter	Datasheet
0…10bar and 0…16bar	4-20 mA	IP65	±%0,5 F.S	24mm

Piezoresistive measuring principle
Stainless steel housing (303)
10 Bar, 16 Bar, 0… -1 Bar, -1… 0 Bar Different options
4-20mA, 0-10 VDC or ratiometric output options
±1% F.S sensitivity
IP65 protection class
Compact construction

For air or non-corrosive gas applications

Datasheet

Measuring Range	Output	Protection	Accuracy	Datasheet
10 Bar, 16 Bar , 0…-1 Bar, -1…0 Bar	4-20 mA, 0-10 VDC, Ratiometric	IP65	±%1 F.S

Thin-film steel diaphragm structure
23 mm diameter stainless steel housing
Different options up to 1000 Bar
Analog 4-20mA / 0-10V etc. outputs
±%0,5 F.S accuracy
Compact design

Fully welded Thin-film steel diaphragm structure that does not require O-rings; High sensitivity; EMC and reverse polarition protection; Small and compact design

Datasheet

Pressure Range	Output	Protection	Accuracy	Body Diameter	Datasheet
Different options up to 1000 Bar	4-20 mA, 0-10 VDC, 0-20 mA, 1-6 VDC, 0-5 VDC, Ratiometric	IP65 or IP67	±%0,5 F.S	23mm
