CLS 210 Capacitive Level Sensor || ATEK || Made in Türkiye

Click to enlarge
Atek

Suitable for water and water based liq
Alarm delay time between 0-40 seconds can be selected at the ordering stage
40 Bar pressure resistance
Sink (NPN) or source (PNP) output type
High accuracy and stability
IP67 protection class

Suitable for level measurement in water and water based liquids, sink (NPN) or source (PNP) output, selectable alarm delay time between 0-40 seconds


Datasheet
TR
EN
Application Max Pressure Temperature Range Output Type Mechanical Connection Protection Datasheet
Water and Water based liquids 40 bar  -40°C … +125°C Sink (NPN) or Source (PNP)  1/4”NPTF, 3/8”NPTF, 1/2”NPTF, 1/2”BSPP, 1/2”BSPT, M14x1.5, M18x1.5  IP67
  • Suitable for water and water based liquids
  • Alarm delay time between 0-40 seconds can be selected at the ordering stage
  • 40 Bar pressure resistance
  • Sink (NPN) or source (PNP) output type
  • IP67 protection class
Brand

Atek
Supply Voltage

9-36VDC
Supply Current

<9mA
Max. Load current

1A (sink), 20mA (source)
Alarm delay time

Standard: 10 sn
Optional: Can be selected by the customer at the ordering stage between 0…40 sn
Connection

4 way Delphi Packard Metri-Pack 150 series connector
Power up delay

0…10sn (factory set)
Power up state

“In liquid” or “out of liquid” (factory set)
Short circuit protection

Yes
Reverse polarity protection

Yes
Overload protection

Yes
Output type

Sink (NPN) or source (PNP)
Output state

Sink: normally open / normally closed (in liquid) (factory set)
Source: normally open / normally closed (in liquid) (factory set)
Body

Brass
Probe

PTFE
Terminals

Brass, tin plated
Seals

FVMQ
Mechanical Connection

1/4”NPTF, 3/8”NPTF, 1/2”NPTF, 1/2”BSPP, 1/2”BSPT, M14x1.5, M18x1.5
Protection

IP67 (with mating connector fitted)
Max. Pressure

40 Bar
Temperature Range

Fluid: -40°C … +130°C
Storage: -40°C … +140°C

Water based liquids, such as coolant or washer fluid, compatible with with brass, PTFE and FVMQ.
