APS 26 Mechanical Plunger Switch || ATEK || Made in Türkiye
Resistant to most oils, fuels, hydraulics, dust and solvents
Mechanical switch for 10mA – 5A at 9-32VDC
Vibration (5G) resistant
Designed to allow both vertical and angular movement
Standard NO, optional NC switch output
IP67 protection class
Oil, fuel, hydraulic and dust resistant; resistant to vibrations; commercial vehicles, industrial equipment, conveyor systems, etc. Status detection and output for many different situations that may occur in systems
| Voltage and Current Range | temperature Range | Body Diameter | Output | Protection | Datasheet |
|---|---|---|---|---|---|
| 12-24V / 10mA-5A | -40°C … +150°C | 26mm | NC or NO | IP67 |  |
- Resistant to most oils, fuels, hydraulics, dust and solvents
- Mechanical switch for 10mA – 5A at 12-24V/li>
- Vibration (5G) resistant
- Designed to allow both vertical and angular movement
- Standard NO, optional NC switch output
- IP67 protection class
| Brand |
Atek |
|---|---|
| Temperature Range |
-40°C … +150°C |
| Body Material |
AISI304L |
| Actuation pin |
AISI 304L |
| Cable Material |
POM |
| Contact Output Type |
NO (standard), NC (optional) |
| Vibration |
5g / 100 -1000Hz |
| Actuation |
Axial or side |
| Axial Force |
At switch point : 10 – 20N |
| Mechanical Life |
1.2 million cycles |
| Operating Pressure |
1 BAR |
| Voltage Range |
12V – 24V |
| Current Range |
10mA – 5A |
| Max. Load |
135W |
| Max. Tightening |
50Nm |
| Electrical Connection |
AMP 282080-1 connector |
| Protection |
IP67 |
Mechanical switches are used in commercial vehicles, industrial equipment, conveyor systems, etc. It is used to detect last positions and give output for many different situations that may occur in systems.
