RCS K 37 Series Angle Sensor || ATEK || Made in Türkiye
Non-contact measurement
12 bit resolution
User-selectable angle values between 0-360 °
4-20 mA, 0-5VDC, 0-10 VDC or 0.5-4.5 VDC ratiometric output
Connection with sleeve
IP67 protection class
Non-contact angular measurement with magnetic principle; high-accuracy; not affected by environmental conditions; connection with sleeve; long service life
| Measuring Range | Resolution | Output | Protection | Supply Voltage | Datasheet |
|---|---|---|---|---|---|
| Different options between 0…360º | 12 bit | 0.5-4.5V Ratiometric, 0-10V, 0-5V, 4-20mA | IP 67 | 5 VDC or 24 VDC |  |
- Non-contact magnetic measurement
- 12 bit resolution
- User-selectable angle values between 0-360 °
- 4-20 mA, 0-5VDC, 0-10 VDC or 0.5-4.5 VDC ratiometric output options
- Long service life
- Conenction with sleeve
- IP67 protection class
| Brand |
Atek |
|---|---|
| Measuring Type |
Magnetic, non-contact |
| Measuring Range |
Can be produced in the desired range from 0 to 360 ° |
| Resolution |
12 bit |
| Linearity |
±%0.5 FS |
| Repeatability |
0.1° |
| Response Frequency |
250 Hz |
| Output Signal |
Rasyometrik ( Supply: 5 VDC, Load : ≥ 1KΩ) |
| Reverse Polarity Protection |
Evet, sadece besleme |
| Current Consumption |
30 mA maks |
| Operating Temperature |
-25…+85 °C |
| Electrical Connection |
3 x 0,14 mm² shielded cable |
| Max. Operating Speed |
3000 rpm |
| Protection Class |
IP67 |
| Material |
Body: Aluminum |
- Robotic systems
- Auto parts
- Solar energy and photovoltaic systems
- Automatic Guided Systems
- Crane and lifting systems
- Wind Power Plants
