BCT 26 Pressure Transmitter || ATEK || Made in Türkiye
Piezoresistive working principle
Stainless steel housing (1.4305)
Optional 316L or titanium housing
Different models between 100 mBar and 600 Bar
Analog 4-20mA / 0-10V and so on different outputs
±0.3% F.S accuracy
IP65 or IP67 protection class
Compact construction
Stainless steel body; high sensitivity; EMC and reverse polarization protected; small and compact design
| Measuring Range | Output | Protection | Accuracy | Body Diameter | Datasheet |
|---|---|---|---|---|---|
| Different models from 0…100mbar to 0…600bar Different vacuum models from 0…-100mbar to 0…-1bar | 4-20 mA, 0-10 VDC, 0-20 mA, 1-6 VDC, 0-5 VDC, Ratiometric etc. | IP65 or IP67 | ±%0,3 F.S | 26mm |  |
- Piezoresistive working principle
- 26 mm body diameter
- Long-term excellent operation
- Stainless steel body
- Compact design
- EMC and reverse polarity protection
- Analog 4-20mA / 0-10V and so on different outputs
- Different models between 100 mBar and 600 Bar
| Brand |
Atek |
|---|---|
| Measuring range |
Diffrent models from 0…100mbar to 0…600Bar r |
| Working Principle |
Piezoresistive |
| Maximum Pressure Strength |
300%F.S. ≤700mbar, 200%F.S. <250Bar, 150%F.S ≥250Bar |
| Oring – Sealing |
Standard NBR, optional FKM(Viton) or EPDM |
| Supply Voltage |
4-20 mA: 8 … 32 VDC |
| Current Consumption |
30mA max. |
| Output Signal |
4…20mA (2-wire), 0…20mA (3-wire) |
| Accuracy |
±%0,3 F.S @25ᵒC |
| Response Time |
1ms … nominal pressure |
| Operating Temperature |
-40°C…+85°C |
| Body Material |
Stainless steel body – 1.4305 (AISI303) |
| Electrical Connection |
Socker models DIN43650-A, DIN46350-C, M12 or/br> PUR cable 3 x 0.14mm2 (4,9 mm cable diameter) |
| Protection Classı |
IP65 or IP67** |
| Mounting / Tightening |
15 … 20 Nm |
- Pneumatic Systems
- Air compressors
- Air Cooling-Heating Systems
- Water Pumps
- Liquid tanks
- Medical industry
- Chemical industry
- Textile sector
- Fabric dyeing machines
